Coming soon a new low cost flowmeter:
Body

Aluminium or 304 Stainless Steel

Plastic Wetted Parts Nylon
Bearings Sapphire
Seal Viton
Output Pulse, 1m cable (or longer, or customers connector), or 4-20mA
Connection 1/4 BSPf (or other)
Pressure rating 5 bar (or higher)
Temperature rating 70°C (or higher)
Accuracy ±1% FSD or ±3% FSD
Repeatability 0.2% FSD
Power requirement 8 to 30V dc
Calibration Traceable or uncalibrated
Price Very competitive (and depending on shipment quantities): from
1 off 190 Euros
10 off 160 Euros
100 off 130 Euros
1000 off 99 Euros
5000 off 75 Euros
15000 off pa 65 Euros

0
Designed, built, calibrated and despatched in the UK
CE Marked
Availability: Early 2006
Contact: sales@flowdevices.com
0

0
These pelton wheel flowmeters offer good rangeability and very low flow rate measurement (e.g. 0.15 to 2.5 l/min on diesel). Typical applications are for the measurement of water, petrol and diesel. The standard unit will be available with 1/4 BSP connections but other sizes and styles can be designed and manufactured depending on quantities. Please contact us for any special requirements. A pulse output is standard but a 4-20mA loop powered version will be available.
